pleach Category 6A U/FTP cable has been designed to provide the exceptional performance required to support extremely high speed applications, including 10-Gigabit Ethernet.
The individually shielded pairs ensure maximum transmission, free from the problems of NEXT and Alien Crosstalk. The sheath is a Low Smoke Zero Halogen material, as specified in many public buildings.

Specification
Application: IEEE 802.3: 10Base-T; 100Base-T: 1000Base-T;
10GBase-T Standards: EIA/TIA 568B: ISO/IEC 11801 2nd ed.; draft
IEC 61156-5 2nd ed.; EN 50173-1; draft EN 50288-10;
RoHS2002/95/EC
Fire rating: IEC 60332-1; IEC 60754-1; IEC 60754-2; IEC 61034
Conductor: bare copper wire (AWG 23)
Insulation: Polyethylene, ? 1.45 mm
Drain wire: Tinned copper
Individual shield around each pair: Alu/Polyester tape
Sheath: LSZH Ivory
Bending radius: = 35 mm without load; = 70 mm with load
Temperature range: during operation -20oC upto + 60oC
during installation 0oC upto + 50oC
Outer diamenter: 8.0 mm
Fire Load: 674 MJ/km; 0.187 kWh/m
Weight: 57 kg/km
Drum weight (Loaded 500m): 32kg
Max pulling tension: 78N

Specification
DC loop resistance: 146.4 O /km
Resistance unbalance: = 2%
Insulation resistance (500 V) = 5000 MO km
Capacitance unbalance (pair to ground) = 1600 pF/km
Characteristic impedance: @100 MHz 100 ± 5 O
Nominal velocity of propagation: approx. 78%
Transfer Impedance (m/m) 1MHz 10MHz 30MHz 100MHz
= 50 = 50 = 70 = 100

Ordering Information
Product Description Part Number
CCS Category 6A U/FTP Solid Cable 001-003-003-06
